RT14 Flow Rate & Totalising Transmitter Display-FRT141D0FM

Flomec's RT14 is a fully programmable, battery powered flow rate totalizer specifically designed for use with flowmeters with frequency outputs. The instrument displays resettable (batch) total, accumulated total and instantaneous flow rates in engineering units as programmed by the user. Available as either standard or ATEX EEx ia versions

• Battery or DC powered
• Backlit ** 8-digit LCD total & 8-digit cumulative totalizer, 5-digit rate display
• Robust IP66/67 GRN enclosure with rubberized buttons and polycarbonate window
• Scaled pulse**, 4-20mA (Loop Powered) Output**
• 10 point linearisation
• Flow alarm for high, low or high/low**
• ATEX EEx ia version
• PIN protected programming
• Simple flowchart touch key programming
• Flowmeter and pipe mount kits available
